Protection : IPX5
Total suction : 8M
Suitable for use with clean water, easy to use and economical
Ideal for domestic use and in particular for distributing water in combination with small pressure sets and for the irrigation of gardens
Maximum fluid temperature up to +60℃
Total suction: 8M
Copper winding
Built-in thermal protector
Insulation Class F
Protection IPX5
Different cable length
Voltage and Frequency 50Hz or 60Hz
1) Silent operation
2) Concise design
3) Can resist chemical in swimming pool
4) Nice performance
5) Anodized motor body
6) Overload protection
7) Huge pro-filter for less cleaning maintenance
8) Heighten pump base to keep water pump off water or moist working environment
9) Arrange drain device of water pump
(According to our general sales conditions)
Model |
Power |
Voltage |
Frequency |
Max. Flow |
Max. Head |
Max. Suction |
|
kW |
HP |
V |
Hz |
(L/min) |
(M) |
(M) |
|
HCP180 |
0.18 |
0.25 |
220-240 |
50 |
160 |
6.5 |
1 |
HCP250 |
0.25 |
0.37 |
220-240 |
50 |
165 |
7 |
1 |
HCP370 |
0.37 |
0.55 |
220-240 |
50 |
210 |
11 |
1 |
HCP550 |
0.55 |
0.75 |
220-240 |
50 |
230 |
12 |
2.5 |
HCP750 |
0.75 |
1 |
220-240 |
50 |
250 |
13 |
2.5 |
HCP1100 |
1.1 |
1.5 |
220-240 |
50 |
295 |
15 |
2.5 |
HCP1500 |
1.5 |
2 |
220-240 |
50 |
350 |
17 |
3 |
HCP2200 |
2.2 |
3 |
220-240 |
50 |
420 |
18 |
3 |
HCP3000 |
3 |
4 |
220-240 |
50 |
500 |
18.5 |
3 |
