270W to 290W Poly-crystalline 60 Cell Solar Panel

Front cover (material /thickness)

low-iron tempered glass /3.2mm

Backsheet (color)

TPT in white

Cell (quantity / material / dimensions)

60/polycrystalline silicon/156.75x156.75mm

Frame (material/color)

aluminum hollow-chamber frame on each side anodized aluminum alloy / silver

Junction box (protection degree)

≥lP68

Cables & Plug connectors

2x900mm / 4㎟ & MC4compatible

Solar Dimensions ( L / W / H )

1640x992x35mm (A) / 1650x990x35mm (B)

Solar Weight

17.75kg

Application class

Class A

Electrical protection class

Class ll

Fire safety class

Class C

Container Size

Units / pallet (PSC)

Weight / Pallet

 (KG)

Pallet Measurment

(mm)

Units / Container

(PCS)

20GP

30

560

1700x1120x1120

360

40HQ

30

560

1700x1120x1120

938

37

688

1700x1120x1385

Panel type : ESM60P

270M

275M

280M

285M

290M

Maximum Power (Wp)

270W

275W

280W

285W

290W

Open circuit Voltage (Voc)

37.4V

37.6V

37.8V

38V

38.2V

Short circuit Current (lsc)

9.14A

9.25A

9.36A

9.47A

9.58A

Maximum Power Voltage (Vm)

31.8V

32V

32.2V

32.4V

32.6V

Maximum Power Current (lm)

8.5A

8.6A

8.7A

8.8A

8.9A

Solar efficiency

16.5%

16.9%

17.2%

17.4%

17.7%

Maximum Series Fuse

15A

Watts positive tolerance

0~+3%

Number of Diode

3

Standard Test Conditions

1000W/㎡,25°C，AM1.5

Maximum System Voltage

1000V/DC

Temperature-Coefficient Isc

+0.08558%/℃

Temperature-Coefficient Voc

-0.29506%/℃

Temperature-Coefficient Pmpp

-0.38001%/℃

Normal Operating Cell Temperature

-40℃….+85℃

Load Capacity for the cover of the solar (glass)

5400Pa (IEC61215) (snow)

Load Capacity for the front & back of the solar

2400Pa (IEC61215) (wind)

Product Certificate

TUV (IEC 61215,IEC 61730),CE,

ROHS,PID Resisitant,INMETRO

Company Certificate

ISO9001,ISO14001,ISO18001
